INTERIOR (L X W X D)
17.00" x 11.70" x 6.20" (43.2 x 29.7 x 15.7 cm)
EXTERIOR (L X W X D)
18.20" x 13.40" x 6.70" (46.2 x 34 x 17 cm)
LID DEPTH: 2.00" (5.1 cm)
BOTTOM DEPTH: 4.20" (10.7 cm)
TOTAL DEPTH: 6.2" (15.7 cm)
INT VOLUME: 0.71 ft³ (0.02 m³)
WEIGHT WITH FOAM: 7.10 lbs (3.2 kg)
WEIGHT WITHOUT FOAM: 5.90 lbs (2.7 kg)
BUOYANCY: 45.64 lbs (20.7 kg)
MINIMUM TEMPERATURE: -20° F (-29 ° C)
MAXIMUM TEMPERATURE: 140° F (60 ° C)
CERTIFICATIONS: MIL-STD-810F / ATA 300 / FED-STD-101C
BODY: Injection Molded HPX® high performance resin
LATCH: Valox - Polybutylene Terephthalate (PBT)
LATCH (ALT): Xenoy - Polyester/Polycarbonate blend
O-RING: EPDM
PINS: Stainless Steel
PINS (ALT): Aluminum
FOAM: 1.3/1.35 polyester
PURGE BODY: Valox - Polybutylene Terephthalate (PBT)
PURGE BODY (ALT): Xenoy - Polyester/Polycarbonate blend
PURGE VENT: Gortex membrane
PURGE O-RING: Buna-N, 50-60 Durometer Shore A
